In celebration of ten years and hence the xSOGN moniker, this complete allroad bicycle is a Rawland for everyone, everywhere that is 98% assembled for $1,699 including FedEx shipping to anywhere in the contiguous US. In keeping with the venerable SOGN design platform, the xSOGN features Rawland STAAL seamless chromoly butted tubing with low-trail geometry, tire clearance for up to 60mm or 47mm with fenders, and an array of integrated and braze-on mounts, all of which are ideal for commuting to trekking and anything in between. The xSOGN also keeps up with the times by featuring 650b Road Plus tires, flat-mount disc calipers, through-axles dropouts, tubeless compatible rims and a 1x road drivetrain. Available as complete bike in three frame sizes for a wide range of standover heights. Now in stock.
Geometry
|
Frame Size |
Small |
Medium |
Large |
|
Head Tube Angle |
73.0 |
73.0 |
73.0 |
|
Seat Tube Angle |
74.0 |
73.5 |
73.0 |
|
Seat Tube Length |
44cm |
51cm |
58cm |
|
Top Tube Length |
53cm |
56cm |
59cm |
|
Stack |
53cm |
56cm |
59cm |
|
Reach |
377mm |
393mm |
409mm |
|
Top Tube Upslope |
15 degrees |
10 degrees |
5 degrees |
|
Head Tube Length |
86mm |
117mm |
148mm |
|
Chainstay Length |
45cm |
45cm |
45cm |
|
Bottom Bracket Drop |
69mm |
69mm |
69mm |
|
Fork Rake |
70mm |
70mm |
70mm |
|
Trail |
32mm |
32mm |
32mm |
|
Wheelbase |
1039mm |
1064mm |
1089mm |
|
Standover Range |
72cm – 78cm |
77cm – 83cm |
82cm – 88cm |
|
Toe Overlap |
Nope |
Nah |
Nei |
|
Stem Length |
90mm |
90mm |
90mm |
|
Handlebar Width |
42cm |
42cm |
42cm |
|
Crankset Length |
165mm |
170mm |
172.5mm |
|
Steerer Length |
110mm |
110mm |
110mm |
Build Specifications
- FSA headset, sealed retainer bearings
- Kalloy Road stem, 31.8mm bore and 28.6mm steerer diameters
- Kalloy Road handlebars, 42mm outside width ideal for low-trail geometry
- Tektro MD-C510 disc calipers, compressionless housing, 160mm rotors
- Tektro RL340 levers
- SRAM Apex 1 crankset, 42t chainring
- SRAM GXP 68mm bottom bracket
- Kalloy Road seatpost, 27.2mm diameter, 350mm length
- Velo VL1352 saddle
- SRAM Apex 1 rear derailleur
- SRAM SL-500 Aero shifter
- SunRace 11-42t cassette
- KMC X11 chain
- Formula Road Thru-Axle hubs, 15x100mm front, 12x142mm rear
- Aluminum bolt-on hub axles
- Alexrims MD21 rims, 21mm inside width, 26mm outside width, 18mm height
- WTB Byway Road Plus, 47mm, tubeless ready tires
- Wellgo B311 pedals
- Sunrise in Northfield Orange
- Electrophoretic deposition (ED) protective coating with clear topcoat
Notes
- The xSogn will be available again soon.
- Although the xSOGN is 98% assembled, we strongly recommend bringing your xSOGN to your favorite local bicycle shop for assembly, adjustment, and fitting.
- The Rando and Demiporteur racks shown above are available separately.
- The 60mm tires shown above are for demonstration purpose.
- Raidoverks Quick Release Through-Axles are available separately.
- Upgrade fork made with Pacenti MTB crown may be available in a couple months.
- Specifications and the contents of this site are subject to change.
- All xSogn bikes include a limited three-year warranty.
- Visit us on Instagram @RawlandCycles for more pictures and updates.
- Email us at ride@rawlandcycles.com if you have any questions.
